Parameters
High voltage generator Power 80kW
kV Range 40～150kV
mA Range 10～1000mA
mAs Range 0.1-1000mAs
Working Frequency 500kHz
Exposure time 0.001S～6.3S
X-ray tube Nominal X-ray tube voltage 150kV
Anode heatstorage 600KHU
Angle 12°
Focus 0.6/1.2mm
Collimator Inherent filtration 1.0mm Al /75kV
Light Source LED
Radiographic Table Top Table Size 2300×800
Bucky Size 18×18inch
Table longitudinal movement ≥790mm
Cassette Movement Distance ≥210mm
Vertical Chest Stand Vertical moving range ≥1550mm
Bucky Size 18×18inch
X-ray generator
Rich DR upgrade reserve interface
Fault self-diagnosis and protection
Automatic calibration of tube current
X-ray tube has the function of filament dormancy
Analog - digital double - loop control, simple operation, high intelligence
High kV, high current, high power,strong penetration,able to handle obese patients
X-ray tube and BUCKY automatic tracking
Ball tube column (manual mode and electric mode switch)
Horizontal movement range of the column: 1760mm±3%
Longitudinal movement range of the column: 1500mm±3%
The lowest point of the center of the ball tube from the ground: 470mm±3%
Tube rotation Angle: ±180 (manual)
BUCKY column (manual mode and electric mode switch)
BUCKY up and down travel: 1550mm±3%
Minimum ground height of BUCKY center: 470mm±3%
Lifting bed (electric mode)
Bed panel size: 2300mmX800mm
Floating bed longitudinal movement range: 790mm±3% (foot control)
Horizontal movement range of floating bed: 210mm±3% (foot control)
Minimum distance from the ground: 524mm±3%
Floating bed lifting range: 270mm
Moving range of flat detector tray: 650mm±3%
Detector
Dimension (L×W×H):460mmx460mmx15mm
X-ray Energy: 40-150kV
Scintillator: CsI:Tl
Pixel Size: 139um
Fill Factor: 70%
Effective Array: 3072x3072
Effective Area (H x V): 427mm×427mm
Spatial Resolution: Min. 3.6 lp/mm
Image Transfer: Wire
Acquisition workstation
Support professional tools
Print and storage
Support different brand of X-ray generators
Image post-processing
Support RIS/PACS/DICOM Printer Connection
Patient management
Computer& LCD
CPU: I3
Memory: ≥8GB
Disk Capacity: ≥1000G
Medical LCD: 23 inch
