The YSGBS-9N is a multifunctional portable flexible endoscope featuring a 3.5-inch high-resolution display. It offers one-touch camera operation, electronic zoom, and adjustable image brightness, facilitating easy observation and accurate detection of diseased tissue. Its ergonomic design allows smooth and quick navigation to the desired site, enhancing diagnostic efficiency. The device is also designed for easy disassembly, cleaning, and disinfection, making it ideal for ENT examinations in various clinical settings.
The multifunctional intubation portable flexible endoscope using polycarbonate new composite handle, reasonable designed the clamp hole position, the washable pipe system can protect the lotion unobstructed, to prevent the pipeline blockage. When doing surgery, the suction valve is convenient, removable, safe and reliable, so that users do not feel fatigue in the operation.
The excellent operation of the traction device an be easily transfer and adjust the bending parts to upward, downward. Can smoothly and fastly reach to the desired site of observation. And timely and accurate detection of diseased tissue.
The multi-function portable flexible endoscope with 3.5 inch high-resolution display, with a key camera video image brightness electroinc zoom, madiation, easy removal and disassembly for cleaning and disinfection.
The scope with multi-coated high transmittance imaging system, round field of view, wide viewing angle, wide field of view, the scene is broad and wide, 3-50 mm range can see more clear picture, so that the observation and diagnosis correctness greatly improved.
The high-definition CMOS camera makes users to get clearer, wider and brighter image.
Portable Video Nasopharyngoscope YSGBS-9N Parameters
Item Nasopharyngoscope
View of field 90°
Diameter of distal-end 5.0mm
Outer diameter of insert tube ф5.0mm
Depth of view 3-50mm
Bending angle Up 160° Down 130°
Clamp aperture 2.0mm
Working length 410mm
LCD 3.5''
Portable Video Nasopharyngoscope YSGBS-9N Packing List
Name Unit Quant
Portable scope set 1
Leak detector set 1
Biopsy forceps pc 2
Cleaning brush pc 2
Attract valve anti jet cover set 2
Endoscope case set 1
3.5" LCD set 1
Charger set 1
Video Output line pc 1
Certificate pc 1
User manual pc 1
Light guiding line pc 1
